Low Noise Amplifier

Single Stage LNA:
Part Number Data Sheet Start Freq. Stop Freq. Gain dB NF dB Gain Flatness P1 dBm IP3 dBm DC Pow. (Volt)
DC Pow (mA)
ECCN
Price
Order Now
LNA50M500M PDF 50M 500M 23 1.0 N/A 20 36 5 85 EAR99 89.99 Order
LNA50M500MH PDF 50M 500M 26 0.9 N/A 22 39.5 5 125 EAR99 89.99 Order
LNA100M2P0G PDF 100M 2G 20 0.45 N/A 20 36 3~5 68 EAR99 79.99 Order
LNA700M6P0G PDF 0.7G 6G 20 0.4 N/A 20 35 3~5 70 EAR99 79.99 Order
LNA050M4P0G PDF 50M 4G 18 0.8 N/A 22 35 5 46 EAR99 79.99 Order
LNA50M6G PDF 50M 6G 17 0.6 N/A 23 37 5 115 EAR99 79.99 Order
LNA600M4P2G PDF 0.6G 4.2G 19 0.6 2dB 19 37 3~5 65 EAR99 79.99 Order
LNA600M4P2GH PDF 0.6G 4.2G 19 0.6 2dB 21 41 3~5 120 EAR99 89.99 Order
LNA600M6GFG PDF 0.6G 6G 21 0.9 2dB 19 35.5 3~5 56 EAR99 99.99 Order
LNA500M8G PDF 0.5G 8G 20 1.3 2dB 20 35 5 60 EAR99 125.00 Order
LNA2G18G PDF 2G 18G 20 1.4 N/A 14 20 3.3~5 60 EAR99 176.99 Order
LNA5G11G PDF 5G 11G 20 1.8 1dB 16 28 3.5 80 EAR99 179.99 Order
LNA6G17G PDF 6G 17G 19 1.7 N/A 14.5 25 3.5 80 EAR99 179.99 Order
LNA6G18G PDF 6G 18G 22 1.5 1dB 11 23 3 52 EAR99 186.99 Order
LNA7G14GFG PDF 7G 14G 17 1.8 1dB 13 25 3 51 EAR99 229.99 Order
LNA6G20G PDF 6G 20G 22 2.5 2dB 11 21 3 60 EAR99 259.99 Order
LNA100M4G PDF 100M 4G 13 1.3 N/A 23.6 41 5 125 EAR99 79.99 Order
LNA500M4G PDF 500M 4G 20.6 1.3 N/A 22 36 5 85 EAR99 89.99 Order
LNA500M4GH PDF 500M 4G 21.8 1.3 N/A 22 39.5 5 125 EAR99 89.99 Order

Single Stage LNA with Low Drop-out Voltage (LDO) Regulator:

LNA with LDO can provide very wide voltage operation range.  The LNA can be powered by batteries, adapter power supply and many other power sources.

Part Number Data Sheet Start Freq. Stop Freq. Gain dB NF dB Gain Flatness P1 dBm IP3 dBm VSWR (IN) VSWR (OUT) DC Pow. (Volt)
DC Pow (mA)
ECCN
Price
Order Now
LNA50M4GR PDF 50M 4G 18 0.8 N/A 22 35 N/A N/A 6~15 40 EAR99 129.99 Order
LNA100M2GR PDF 100M 2G 20 0.45 N/A 20 36 N/A N/A 5~15 68 EAR99 159.99 Order
LNA600M4P2GR PDF 0.6G 4.2G 19 0.6 2dB 19 37 N/A N/A 5~15 65 EAR99 179.99 Order
LNA600M6GFGR PDF 0.6G 6G 21 0.9 2dB 19 35.5 N/A N/A 5~15 56 EAR99 179.99 Order
LNA700M6GR PDF 0.7G 6G 20 0.4 N/A 20 35 N/A N/A 5~15 70 EAR99 159.99 Order

 Cascaded Two Stage High Gain LNA:

Part Number Data Sheet Start Freq. Stop Freq. Gain dB NF dB Gain Flatness P1 dBm IP3 dBm VSWR (IN) VSWR (OUT) DC Pow. (Volt)
DC Pow (mA)
ECCN
Price
Order Now
LNA50M4G2S PDF 50M 4G 36 0.8 N/A 22 35 N/A N/A 5 108 EAR99 179.99 Order
LNA100M2G2S PDF 100M 2G 40 0.45 N/A 20 36 N/A N/A 3~5 135 EAR99 179.99 Order
LNA700M6G2S PDF 0.7G 6G 40 0.4 N/A 20 35 N/A N/A 3~5 140 EAR99 179.99 Order
LNA5250M5455M PDF 5250M 5455M 39 0.85 1dB 19 35 N/A N/A 5 120 EAR99 259.99 Order
LNA600M6GFG2S PDF 600M 6G 39 0.9 +/-2dB 19 35 N/A N/A 5 120 EAR99 259.99 Order
