RF Block Up/Down Converter

USB Software Defined (Programmable) Block Up/Down Converter up to 20 GHz!

  • Integrated LO Generator
  • Two Functions in one Unit (Up-conversion or Down-conversion)
  • RF Signal Frequency from 2GHz to 20GHz
  • IF Signal Frequency from 500MHz to 6GHz
  • USB-C software programmable LO signal frequency
  • Can be used as Spectrum Analyzer Frequency Extender

Customization is available for the following added features:

  • IP67 waterproof with sealed D-Sub Connectors
  • RS485/RS232 legacy communication support
  • Multiple Channels Up/Down conversion
  • LED indication of PLL Lock Status
  • Wider Voltage Operation Range 7V~34V
  • Add Low/High/Bandpass Filter before/after conversion to filter out image signal
Part Number Data Sheet

LO Freq. (GHz)

RF Freq. (GHz) IF Freq. (GHz) RF Return Loss (dB) LO Input Return Loss (dB) IF Return Loss (dB)
Conversion Loss (dB)
LO to RF Leakage (dBm)
LO to IF Leakage (dBm) RF to LO Isolation (dB) RF to IF Isolation (dB) Input 1dB Compression (dBm)

Voltage (V)

Current (mA)
ECCN
Price
Order Now
BUDC2G14G PDF 1~12 2~14 0.5~6 >9 >10
>10
~9 typ. <-30
<-27 >45 >35 14

5~6 or USB-C

235 EAR99 1397.95 Order
BUC3G6G PDF 6.5 3~6 0.5~3.5 >9 >10 >10 ~9 typ. <-30 <-27 >45 >35 14 5~6 or USB-C 420
EAR99 1697.95 Order
BUDC3G20G PDF 1~20 3~20 0.5~9 >9 >10
>10
~9 typ. <-25 <13 >40 >32 16 5~6 or USB-C 355 EAR99 1797.95 Coming Soon
