  • 6UDD2W6H41SMAA1 Enclosure Kit for 0.020"/0.5mm PCB (9/16"x9/16") 1 SMA Active 0.48" Height

    Part Number: 6UDD2W6H41SMAA1 is RF Designer Kit is for prototyping with PCB size 9/16"x9/16"x0.020"(or 0.5mm).

    RF Housing Size: 5Ux5U (15/16"x15/16"). Each U is 3/16". Housing height: 0.41" (without Cover). The PCB mounting hole spacing is 0.375" and 0.375" respectively. PCB Inside Clearance to Enclosure Cover is 0.19". SKU#: AK20-010B.

    Proudly Made in USA by Lotus Communication Systems, INC. in Weston, Massachusetts.

    RF Kit include (PCB is not included):

    • All CNC Machined Housing and Cover, 1 ea
    • SMA 2-Hole Flange Jack Receptacle Connector, 0.086", 0.012" Pin, 1 ea
    • EMI Feedthrough Cap #2-56, 100V/5A, 1ea
    • Ground Solder Terminal #2-56, 1 ea
    • 2-56x3/16" SHCS, 4 for SMA Connector
    • 2-56x5/32" SHCS, 4 for PCB
    • 2-56x3/16" Flat Head Screw (for Cover), 4 ea


    • Hold PCB Size 9/16"x9/16"x0.020" (or 0.5mm)
    • Clearance from PCB top to Enclosure Cover (0.19")
    • All CNC Machined Surface for Superior Finish and Minimize RF Leakage
    • 4 Installation Holes to Mount Kit to Back Board with #2 SHCS
    • 3/16" Wall Thickness for Strong Mechanical Strength
    • Two SMA Connectors
    • Electroless Nickel Plating per MIL-C-26074, ASTMB 733
    • Professional Zebra Ultimate Label for Outdoor Usage
    • Proudly MADE IN USA (Material & Labor)
    • ROHS Compliant
